ABB AX411/50001

CPU板包含微处理器和RAM内存、实时时钟、LED指示灯、INIT按钮和CompactFlash接口PM858控制器的底板上有2RJ45以太网接口(CN1、CN2)和2RJ45口(COM3、COM4),用于连接到控制网络，其中一个串口(COM3)是带有调制解调器控制信号的RS-232C端口,而另一人端口(COM4是隔窗的，用于连接配置工具，控制/器支持PU余，提供更高的可用性(CPU、Cex总线、通信接口和S800 1/0)。

简单的DIN导轨连接/分意程序，使用独特的滑动和锁定机制。所有的底板都有一个唯一的以太网地址，它为每个CPU提供了一个硬件标识。该地如可以在TP830底板上的以太网地址标签上找到。

(仅兼容System 800xA 6.0.2,Compact Control Builder 6.0.0-1及以上版本，请参阅产品更新了解更多信息。)

特点和优点

·ISA安全认证-了解更多

。可靠性和简单的故障诊断程序

模块化，允许逐步扩展

IP20级防护，不需要外壳

控制器可配置800xA控制生成器

控制器通过EMC全认证

·cex总线采用一对BC810/BC820

·基于最佳通信连接标准的硬件

(以太网、PROFIBUS，DP等

内置冗余以太网通信端

The CPU board contains a microprocessor and RAM memory, real-time clock, LED indicator lights, INIT button, and CompactFlash interface. The PM858 controller has 2RJ45 Ethernet interfaces (CN1, CN2) and 2RJ45 ports (COM3, COM4) on the backplane, which are used to connect to the control network. One of the serial ports (COM3) is an RS-232C port with a modem control signal, The other port (COM4) is windowed and used to connect configuration tools. The control/controller supports PU redundancy, providing higher availability (CPU, Cex bus, communication interface, and S800 1/0).

Simple DIN rail connection/separation program, using unique sliding and locking mechanisms. All backplanes have a unique Ethernet address that provides a hardware identifier for each CPU. The location can be found on the Ethernet address label on the TP830 backplane.

(Only compatible with System 800xA 6.0.2, Compact Control Builder 6.0.0-1 and above. Please refer to product updates for more information.)

Features and advantages

·ISA Security Certification - Learn More

. Reliability and simple fault diagnosis program

Modular, allowing for gradual expansion

IP20 level protection, no shell required

Controller configurable 800xA control generator

The controller is fully certified by EMC

·The cex bus adopts a pair of BC810/BC820

·Hardware based on optimal communication connection standards

(Ethernet, PROFIBUS, DP, etc.)

Built in redundant Ethernet communication terminal
