处理器

CompactLogix控制器可以通过本地I/O或者分布式扩展I/O（经DeviceNet或Ethernet/IP）实现实时控制。CompactLogix控制器可以使用RS-232口（DF1/DH-485协议）、DeviceNet以及EtherNet/IP网络与计算机或其它处理器通讯。

1. 控制器：A-B 1756-L61S

l 用户内存：512KB；

l 具有2个内置的RS-232口；

l 本地扩展I/O容量达到3组16个I/O模块；

l 支持多层网络的无逢集成和数据路由，这意味着用户可以方便地自动实现跨多层网络的远程设备访问、组态和诊断；

l 支持4个可组态任务；

processor

The CompactLogix controller can achieve real-time control through local I/O or distributed extended I/O (via DeviceNet or Ethernet/IP). The CompactLogix controller can communicate with computers or other processors using RS-232 ports (DF1/DH-485 protocol), DeviceNet, and EtherNet/IP networks.

1. Controller: A-B 1756-L61S

User memory: 512KB;

Equipped with 2 built-in RS-232 ports;

Local expansion of I/O capacity up to 3 sets of 16 I/O modules;

Support seamless integration and data routing for multi-layer networks, which means users can easily and automatically achieve remote device access, configuration, and diagnosis across multi-layer networks;

Support 4 configurable tasks;
