A-B 81003-438-51-R

支持符合 EtherNet/IP TCP/CIP 连接 96 的单网络策略

为 DLR 和线形拓扑提供双以太网端口

通过 EtherNet/IP 上的分布式 I/O 简化系统架构

通过重新利用现有的 1769 I/O 进行控制移植

I/O 包速率为 10,000 pps

可进行直接连接

1769 Compact 特殊功能 I/O 模块

提供地址预留、ASCII、布尔控制和高速计数器模块

通过 Compact I/O? 转 DPI/SCANport? 和 Compact I/O 转 DSI/Modbus 模块，将 1769 平台直接连接到 PowerFlex? 变频器和其他设备

认证

UL、cULus、KC、C-tick、ODVA、C-UL (CSA) 和 CE 认证；1 类 2 分区危险环境等级

相关产品

I/O 接线和转换系统

Rockwell Automation? PartnerNetwork? 通过 Encompass 产品引荐计划提供 1769 Compact I/O 模块的互补产品解决方案。

附件

我们为 Compact I/O 模块提供了各种附件，包括：

终端盖

扩展电缆

电源

I/O 接线附件

通过我们的 I/O 接线和转换系统 ，可以更快速地安装，减少接线错误，并简化 Allen-Bradley? I/O 的故障处理。

接口模块（IFM、AI FM）、预接线电缆和现场接线电缆可替代端子块，从而减少了点对点接线

接口模块可用于为 I/O 添加端子、状态指示灯和过流保护。

Supports single network policy compliant with EtherNet/IP TCP/CIP connection 96

Provide dual Ethernet ports for DLR and linear topology

Simplify system architecture through distributed I/O on EtherNet/IP

Control migration by reusing existing 1769 I/O

I/O packet rate is 10000 pps

Can be directly connected

1769 Compact Special Function I/O Module

Provide address reservation, ASCII, Boolean control, and high-speed counter modules

Through Compact I/O? Transfer to DPI/SCANport? Connect the 1769 platform directly to PowerFlex using the Compact I/O to DSI/Modbus module? Frequency converters and other equipment

authentication

UL, cULus, KC, C-tick, ODVA, C-UL (CSA), and CE certification; Class 1, Division 2 Hazardous Environment Level

Related products

I/O wiring and conversion system

Rockwell Automation? PartnerNetwork? Provide complementary product solutions for 1769 Compact I/O modules through the Encompass product introduction program.

attachment

We provide various accessories for Compact I/O modules, including:

Terminal cover

Expansion cable

source

I/O wiring accessories

Through our I/O wiring and conversion system, we can install more quickly, reduce wiring errors, and simplify Allen Bradley? I/O fault handling.

Interface modules (IFM, AI FM), pre wired cables, and field wiring cables can replace terminal blocks, thereby reducing point-to-point wiring

The interface module can be used to add terminals, status indicators, and overcurrent protection to I/O.
