A-B 1785-L80B

冗余 I/O 系统，ControlLogix? 控制器无需额外编程或接线即可通过 EtherNet/IP? 网络与远程冗余 I/O 通信。此系统通过使用一对冗余以太网适配器和多个 I/O 模块为关键过程提供容错和冗余。该 I/O 模块提供诊断功能并可以互换，而不会造成控制系统中断。

 特性

支持多种网络拓扑结构（包括设备级环网 (DLR)）以提高网络弹性

为用户可配置 I/O 应用项目提供灵活的模块化结构

为需要高可用性的系统提供 I/O 冗余

适合单工和双工连接以及容错应用项目

运行无需其他的硬件或编程软件

支持在线拆除和更换模块，不会造成信号输入中断

产品

1715 冗余 I/O 模块

1715 冗余 I/O 通信接口

认证

I/O 模块：c-UL-us、CE、C-Tick、Ex、KC、GOST

通信模块：c-UL-us、CE、C-Tick、Ex、KC、EtherNet/IP、GOST

I/O 模块

Bulletin 1715 冗余 I/O 模块为标准和极端运行环境中的关键过程应用项目提供真正的冗余 I/O 支持。这些模块具备出色的易用性、优异的诊断和灵活的配置，无需其他硬件或软件即可支持容错功能。

通信接口

通过 Bulletin 1715 通信适配器，1715 I/O 模块能够与 ControlLogix? 或 CompactLogix? 可编程自动化控制器在 EtherNet/IP? 通信网络上交换数据。这些适配器成对使用，可为关键过程应用项目提供容错通信和网络弹性

软件

使用 Rockwell Software? 的 Studio 5000 自动化工程与设计环境，可以设计和配置您的 ControlLogix? 和 1715 冗余 I/O 系统。

您所选择的控制器和模块以及网络配置决定了对系统进行配置和编程所需的附加软件包。其他所需的软件可能包括 RSNetWorx 配置软件和 RSLinx 通信软件。

附件

我们为您的 1715 冗余 I/O 系统提供了各种附件，包括：

适配器和 I/O 模块基本单元

扩展电缆

模块槽盖板

端子组件

Redundant I/O system, ControlLogix? Can the controller be accessed through EtherNet/IP without additional programming or wiring? Network and remote redundant I/O communication. This system provides fault tolerance and redundancy for critical processes by using a pair of redundant Ethernet adapters and multiple I/O modules. This I/O module provides diagnostic functions and can be interchanged without causing control system interruption.

characteristic

Support multiple network topologies, including device level ring networks (DLR), to improve network resilience

Provide flexible modular structure for user configurable I/O application projects

Provide I/O redundancy for systems that require high availability

Suitable for simplex and duplex connections and fault-tolerant application projects

No additional hardware or programming software required for operation

Supports online removal and replacement of modules without causing signal input interruption

product

1715 Redundant I/O Module

1715 redundant I/O communication interface

authentication

I/O modules: c-UL us, CE, C-Tick, Ex, KC, GOST

Communication modules: c-UL us, CE, C-Tick, Ex, KC, EtherNet/IP, GOST

I/O module

The Bulletin 1715 redundant I/O module provides true redundant I/O support for critical process application projects in standard and extreme operating environments. These modules have excellent ease of use, excellent diagnostics, and flexible configurations to support fault tolerance without the need for other hardware or software.

communication interface

Through the Bulletin 1715 communication adapter, the 1715 I/O module can communicate with ControlLogix? Or CompactLogix? Programmable automation controller on EtherNet/IP? Exchange data on communication networks. These adapters are used in pairs to provide fault-tolerant communication and network resilience for critical process application projects

software

Using Rockwell Software? Can you design and configure your ControlLogix in the Studio 5000 automated engineering and design environment? And 1715 redundant I/O system.

The controller, module, and network configuration you choose determine the additional software packages required for configuring and programming the system. Other required software may include RSNetWorx configuration software and RSLinx communication software.

attachment

We provide various accessories for your 1715 redundant I/O system, including:

Adapters and I/O module basic units

Expansion cable

Module slot cover plate

Terminal components
