A-B MSR241P

集中了Logix通用平台的多种优点---通用的编程环境、通用的通讯网络、通用的控制引擎---提供了一个既能满足您高性能应用需求又易于使用的环境。

  Controllogix在编程软件、控制器和输入输出诸方面的紧密集成降低了在试运行和正常操作的开发成本和时间。

◆Controllogix系统以紧凑的、经济的产品提供离散控制、驱动控制、运动控制、过程控制、安全控制、便利的通讯连接、艺术级的输入输出功能。Controllogix系统是模块化的系统，您能有效的设计、建立和修改它，这有助于在培训和工程方面显著的降低成本。

◆真正意义上的冗余控制器结构提供无扰动切换和高可靠性。

◆提供众多的通讯选择、更多的模拟量、数字量和特殊输入输出模块。

◆Controllogix产品通过了TUV认证，能够应用于SIL 2要求的项目中。

Controllogix内容容量最大可扩展到8M,Controllogix控制器支持高标准过程控制应用，提供了在一个单一的集成环境中对运动控制指令进行高速处理的功能。

Controllogix提供了模块化的通讯网络连接选择，您根据您的需要购买相应的通讯模块即可。

Controllogix解决方案同样提供时间同步能力,这个在第一故障条件和过程顺序应用中是特别重要的。

  可以根据应用要求，选用不同存储容量的Controllogix控制器。可用CompactFlash卡做程序的移动存储设备。

  Controllogix系统具有以下优点：

◆适合顺序、过程、传动、运动控制的模块化高性能控制平台

每个Controllogix控制器可以执行多个控制任务，减少需要的控制器数量，这样，解决故障更快。可以分别出发几个周期性任务以达到更高的性能水平。

◆可以在一个机架上使用多个处理器、通讯模块和输入输出模块

Controllogix处理器、输入输出模块、通讯模块就像网络上的智能节点。

◆通用的编程环境和Logix控制引擎。Controllogix与CompactLogix、FlexLogix、SoftLogix、  DriveLogix都是基于通用Logix平台建立的，它们具有通用的编程环境和Logix控制引擎。

◆连接到NetLinx开放式网络

从设备到车间再到信息管理层，Controllogix高度支持三层网络通讯。

  Controllogix的独特之处：

1.产品设计

  Controllogix处理器提供可选的用户内存模块(750K到8M字节),能解决有大量输入输出点数系统的应用问题(支持多达4000点模拟量和128，000点数字量)。处理器可以控制本地输入输出和远程输入输出。处理器可以通过以太网EtherNet/IP、 控制网ControlNet、 设备网DeviceNet和远程输入输出Universal Remote I/O来监控系统中的输入和输出。

  当在Controllogix机架内有多个处理器模块，甚至在控制网ControlNet网内有多个处理器模块时，所有的处理器都可以从所有的输入模块读到输入值。任何一个处理器也都可以控制任何特定的输出模块。通过系统组态指定每个输出模块具体由哪个处理器控制。

  Controllogix系统是机架式、模块化安装。Controllogix输入输出模块是是模块式安装的。电源模块直接安装在Controllogix机架的左端。Controllogix机架有4、7、10、13或17槽五种类型。模块可以插在机架上任意一个槽位内。Controllogix输入输出模块的最大通道数是32通道。每个模块的可拆卸端子块的机械锁可以防止向模块施加错误的电压。输入输出模块可以进行带电插拔。

2.通讯

  除了内置的RS-232(DF1/DH-485协议)通讯口外，网络通讯的接口是模块化的。包括以太网EtherNet/IP, 控制网ControlNet, 设备网DeviceNet, DH+网络, 远程输入输出网络Universal Remote I/O。Controllogix通过第三方的通讯模块也可以连接到Profibus DP和 Modus等网络上。

Controllogix中文选型手册下载：Controllogix选型资料。

Integrating the various advantages of the Logix universal platform - a universal programming environment, a universal communication network, and a universal control engine - provides an environment that meets your high-performance application needs while being easy to use.

The tight integration of Controllogix in programming software, controllers, and input/output reduces the development cost and time for trial operation and normal operation.

The Controllogix system provides discrete control, drive control, motion control, process control, safety control, convenient communication connection, and artistic input and output functions in a compact and economical product. The Controllogix system is a modular system that you can effectively design, establish, and modify, which helps significantly reduce costs in training and engineering.

The truly redundant controller structure provides undisturbed switching and high reliability.

Provide numerous communication options, more analog, digital, and special input and output modules.

The Controllogix product has passed TUV certification and can be applied to projects required by SIL 2.

The content capacity of Controllogix can be expanded up to 8M, and the Controllogix controller supports high standard process control applications, providing high-speed processing of motion control instructions in a single integrated environment.

Controllogix provides modular communication network connection options, and you can purchase corresponding communication modules according to your needs.

The Controllogix solution also provides time synchronization capability, which is particularly important in the application of the first fault condition and process sequence.

Controllogix controllers with different storage capacities can be selected according to application requirements. A portable storage device that can use a CompactFlash card as a program.

The Controllogix system has the following advantages:

Modular high-performance control platform suitable for sequence, process, transmission, and motion control

Each Controllogix controller can perform multiple control tasks, reducing the number of controllers required, resulting in faster fault resolution. Several periodic tasks can be initiated separately to achieve higher performance levels.

◆ Multiple processors, communication modules, and input/output modules can be used in one rack

The Controllogix processor, input/output module, and communication module are like intelligent nodes on a network.

◆ Universal programming environment and Logix control engine. Controllogix, CompactLogix, FlexLogix, SoftLogix, and DriveLogix are all built on a universal Logix platform, with a universal programming environment and Logix control engine.

Connect to NetLinx open network

From equipment to workshop to information management, Controllogix highly supports three-layer network communication.

The uniqueness of Controllogix:

1. Product Design

The Controllogix processor provides optional user memory modules (750K to 8M bytes) that can solve application problems in systems with a large number of input and output points (supporting up to 4000 analog and 128000 digital points). The processor can control local input and output as well as remote input and output. The processor can monitor inputs and outputs in the system through Ethernet EtherNet/IP, control network ControlNet, device network DeviceNet, and remote input/output Universal Remote I/O.

When there are multiple processor modules in the Controllogix rack, and even multiple processor modules in the control network ControlNet network, all processors can read input values from all input modules. Any processor can also control any specific output module. Specify which processor controls each output module through system configuration.

The Controllogix system is a rack mounted, modular installation. The Controllogix input output module is installed in a modular manner. The power module is installed directly on the left end of the Controllogix rack. Controllogix racks come in five types: 4, 7, 10, 13, or 17 slots. The module can be inserted into any slot on the rack. The maximum number of channels for the Controllogix I/O module is 32. The mechanical lock of each module's detachable terminal block can prevent incorrect voltage from being applied to the module. The input/output module can be plugged and unplugged with power.

2. Communication

In addition to the built-in RS-232 (DF1/DH-485 protocol) communication interface, the network communication interface is modular. Including Ethernet EtherNet/IP, control network ControlNet, device network DeviceNet, DH+network, remote input/output network Universal Remote I/O. Controllogix can also be connected to networks such as Profibus DP and Modus through third-party communication modules.

Download the Chinese selection manual for Controllogix: Selection materials for Controllogix.
