EMERSON KJ2221X1-EA1

Ovation DCS是美国爱默生公司的大型自动化控制系统, 其通讯速率为每秒100MB、处理容量为每秒200000 点实时信息, 联网长度达200 km , 节点数最多1 000 个。操作员站采用DELL 公司的商用机 , 交换机采用的是CISCO 的产品。该DCS以其支持带电插拔、简洁易用、功能强、组态方便、接线容易等诸多特点深受工控人的喜爱。CCPP采用了冗余Ovation DCS VWestinghouse西屋3.3.1,采用C/S结构，注册码授权，通讯协议采用以太网TCP/IP。服务器安装Windows2003Server英文版，客户端安装WindowsXP英文版。

主要硬件类型有：主副控制器（包括CPU卡、电源卡、通讯网卡、接口卡）、DI卡（开关量输入）1C31234G01、SOE卡（DI卡）1C31233G04、DO卡（带继电器开关量输出，250V AC）5A26457G01、DO卡（带继电器开关量输出, 150VDC）5A26458G02、AI卡（4－20mA输入）1C31224G01/1C31227G01、AI卡（0Westinghouse西屋-10VDC输入）5X00070G03/ 1C31227G02、  AI卡HART Analog Input Module 5X00058G01/ 5X00059G01、TC卡（热电偶）5X00070G04/1C31116G04、RTD卡（热电阻）5X00119G01/5X00121G01、AO卡（4－20mA输出）1C31129G03/1C31132G01、  PI卡（脉冲输入）1C31147G01/ 1C31150G01、   LC卡(串口通讯卡) 1C31166G01/ 1C31169G02等等。 Westinghouse西屋 工艺控制要点包括：余热锅炉燃烧控制、环形真空泵和真空破坏阀控制、管型离相封闭母线技术、快速切换技术、变压器消防排油注氮工艺、闭式循环冷却水控制、循环冷却水增压调节、水源热泵控制、凝汽器中旁路节流减压控制等等。

Ovation DCS is a large-scale automation control system developed by Emerson in the United States, with a communication rate of 100MB per second, a processing capacity of 200000 real-time information points per second, a network length of 200 km, and a maximum of 1000 nodes. The operator station uses DELL company's commercial computers, and the switch uses CISCO products. This DCS is highly favored by industrial controllers due to its support for live plugging, simplicity, strong functionality, convenient configuration, and easy wiring. CCPP adopts redundant Ovation DCS VWesteringhouse Westinghouse 3.3.1, with a C/S structure, registration code authorization, and communication protocol using Ethernet TCP/IP. Install the English version of Windows 2003 Server on the server and Windows XP on the client.

The main hardware types include: main and auxiliary controllers (including CPU card, power card, communication network card, interface card), DI card (switch input) 1C31234G01, SOE card (DI card) 1C31233G04, DO card (with relay switch output, 250V AC) 5A26457G01, DO card (with relay switch output, 150VDC) 5A26458G02, AI card (4-20mA input) 1C31224G01/1C31227G01 AI card (0Westinghouse 10VDC input) 5X00070G03/1C31227G02, AI card HART Analog Input Module 5X00058G01/5X00059G01, TC card (thermocouple) 5X00070G04/1C31116G04, RTD card (thermal resistance) 5X00119G01/5X00121G01, AO card (4-20mA output) 1C31129G03/1C31132G01, PI card (pulse input) 1C31147G01/1C31150G01, LC card (serial communication card) 1C31140G01 1166G01/1C31169G02, etc. The key points of Westinghouse process control include: combustion control of waste heat boiler, control of annular vacuum pump and vacuum breaking valve, technology of pipe type isolated phase enclosed busbar, fast switching technology, transformer fire discharge oil and nitrogen injection process, closed cycle cooling water control, boost regulation of circulating cooling water, control of water source heat pump, bypass throttling and pressure reducing control in condenser, and so on.
