FOXBORO B0123HD实现快速、简便的集成

电源

使用硬芯儿或多芯儿AWG 14 (1.95 mm2)导线。

为保护设备，外接保险丝是必要的。

在中央处理单元和远程单元的底部有一个230Va.c或120 V a.c的选择开关，产品在发货时设定在230Va.c位置。

在120/230Va.c.型号的模块提供内部24Vd.c.电源。最大电流400mA。这个内部电源有短路和过载保护。在这种情况下，故障消除10秒钟后可恢复正常。

它也允许使用外部24Vd.c.供电，在这种情况下，不要忘了把外部外部24Vd.c.电源的接地端连接到端子C上。

输入/输出接线

输入使用硬芯儿或多股导线从AWG18(0.96mm2)到AWG 14(1 .95mm2)，输出使用硬芯儿或多股导线

AWG 14(1.95mm2)

输出保护

继电器输出可以按如下方法抑制由感性负载产生的干扰:

-带交流负载的一个可变电阻或--个RC抑制模块

-带DC负载的惯性二极管

外接的保险丝连接到输出电源的公共端，保护连接到输出的装置。

晶体管输出内部有短路和过载保护。但是，接L/R大于40ms的感性负载时，加装一一个惯性 二极管是必要的。
