Motorola MVME2700-4441

技术规格：

1. 处理器：采用PowerPC 750™ 32位微处理器，具有32KB/32KB L1高速缓存和1MB背面二级缓存。
2. 内存：支持RAM200内存扩展模块，可将内存从16MB扩展到256MB ECC DRAM。
3. 存储：配备8MB板载闪存和1MB插槽式闪存。
4. 接口：
• 64位PCI夹层连接器
• 2或3个异步串行端口
• 1或2个同步/异步串行端口
• 带32位PCI本地总线DMA的以太网收发器接口
• 8位或16位快速SCSI-2总线接口
• 并行、软盘、键盘和鼠标接口
5. 其他：
• 板载调试监视器，带自检诊断功能
• 兼容IEEE P1386.1的32/64位PMC扩展插槽
• 8KB x 8 NVRAM和带可更换备用电池的定时时钟
• 四个32位定时器，一个看门狗定时器

功能特点：

1. 高性能：基于摩托罗拉PowerPlus VME架构和PowerPC®微处理器，提供可扩展的高性能VME计算。
2. 灵活性：通过PMC扩展插槽提供灵活性，支持各种特定行业应用的快速、轻松定制。
3. 大容量内存：使用RAM200内存扩展模块，无需额外的VME插槽即可将内存升级到最大256MB的ECC DRAM。
4. 丰富的接口：提供多种通信和I/O接口，满足不同应用需求。

应用场景：

专为满足军事、航空航天、工业自动化和医疗需求而设计，适用于各种高性能计算、数据处理和通信应用。其高性能、高可靠性和可扩展性使其成为这些领域中的理想选择。
