ABB DSTD108

硬件配置

每一个CPU可以操作多达4个外部通讯卡(如果存在，包括内部通讯卡)。依靠所选择的通讯协议，每-一个通讯卡可作为带有几种现场总线的AC500控制系统内的总线主站和网络。可以越过端子底板上的内部通讯卡总线直接给通讯卡供电。无需单独的电压源。

用途

AC500 CM572-DP通讯模块能够在PROFIBUS DP现场总线上进行通讯。通讯卡安装在同一端子底板上CPU的左侧。CPU与通讯卡之间的通讯是通过集成在端子底板上的通讯卡总线(通讯卡接口)进行的。数据交换是通过双C ]RAM来实现。依据所用的端子底板，可使用1、2或4个通讯卡(也可为不同类型)

安装与电气连接

通讯卡安装在同一端子底板上CPU的左侧。安装通讯卡时自动建立电气连接。

Ethernet通讯-卡是智能的100-Base-T-Ethernet通讯接口，它基于高度集成的微控制器EC1。此通讯:卡支持完

整的TCP/IP协议，也支持应用层协议。

用户接口基于双端C ]存储器。此通讯卡符合PC/104标准。Ethernet通 讯通过RJ45接C l进行。

利用系统配置工具通过双端口存储器、诊断接口或TCP/IP连接来配置通讯卡。配置非易失性地被保存在Flash EPROM中。

应用:

TCP/IP用于PC/Control Builder (编程)

UDP (通过ETH_ _UDP_ _SEND和ETH_ _UDP_ REC功能块进行通讯)在TCP/IP之上的Modbus(在TCP/IP之上的Modbus,主站和从站)
