ABB DSAO110

系统集成了满足过程控制中最具挑战性和最矛盾的要求的设备。它包括广泛的IO模块，以涵盖所有电力电子控制要求不同的I/O模块可以连接到AC 800PEC控制器，以满足以下大多数自动化要求:·加工工业

·发电和配电

·交通和牵引。

模块化，节能设计的AC 800PEC允许操作没有强制冷却。

这些模块安装在标准的DIN导轨上，可以很容易地安装在分布式过程中

可直接连接的I/0系统的数量仅受到处理器的最大可用光纤链路(36条双向路)的限制。根据需要的性能，模块之间可以使用单链路、多链路或几余

的双向链路。

每个模块包括一个机械载体、一个基本模块和一组可配置的子模块，这些子模块提供所需的I/0终端或通信接口。

AC 800PEC控制器PP D113

该控制器由低功耗电路组成，具有高可靠性。硬件可以自由配置，根据工艺要求和选择的通信与上层控制。AC 800PEC控制模块包含处理器、外设I/0光接口、现场总线和上位控制器接口:·基础单元AC 800PEC BP(背板插槽用于安装处理器，电源，光学和通信模块)处理器模块AC 800PEC PU安装在AC 800PEC BP上，CPU是一个功能齐全的750 MHz RISC处理器，带有64位1EEE浮点单元(FPU)，它针对控制周期非常快的应用进行了优化

·两个AnvIO接口，每个接口由

AnvBus?- s插槽

一个额外的AnyIO扩展插槽

ac800pec CEX接口或特殊应用

The system integrates equipment that meets the most challenging and contradictory requirements in process control. It includes a wide range of IO modules to cover all power electronic control requirements. Different I/O modules can be connected to AC 800PEC controllers to meet most of the following automation requirements: · Processing industry

·Power generation and distribution

·Transportation and traction.

The modular and energy-saving design of the AC 800PEC allows for operation without forced cooling.

These modules are installed on standard DIN rails and can be easily installed in distributed processes

The number of I/O systems that can be directly connected is only limited by the maximum available fiber optic link (36 bidirectional paths) of the processor. Depending on the required performance, modules can use single link, multi link, or more

The bidirectional link of.

Each module includes a mechanical carrier, a basic module, and a set of configurable submodules that provide the required I/O terminals or communication interfaces.

AC 800PEC controller PP D113

The controller consists of low-power circuits and has high reliability. Hardware can be freely configured according to process requirements and selected communication and upper level control. The AC 800PEC control module includes a processor, peripheral I/O optical interface, fieldbus, and upper controller interface: · Basic unit AC 800PEC BP (backplane slot for installing processor, power supply, optical, and communication modules) Processor module AC 800PEC PU is installed on the AC 800PEC BP. The CPU is a fully functional 750 MHz RISC processor with a 64 bit 1EEE floating point unit (FPU), which is optimized for applications with very fast control cycles

·Two AnvIO interfaces, each composed of

AnvBus- S slot

An additional AnyIO expansion slot

AC800pec CEX interface or special application
