ABB PPD115A102

传动单元包括下列标准印刷电路板:

●主电路接口板(AINT) ;

●电机控制和/O电路板(RMIO-02)(与AINT通过光纤连接) :

●输入桥路控制板(AINP) ;

●包括压敏电阻和用于可控硅整流器的缓冲器的输入桥路保护板(AIBP);

电源供应板(APOW) :

●门极控制板[AGDR-61 或AGDR-62 (带du/dt 限制选项+E204)] ;

●诊断和控制盘接口板(ADPI) :

●带选项+E202的EMC滤波器板(NRFC和ARFC);

●带选项+D150的制动斩波器控制板(ABRC)。

调试传动单元并将其投入使用之前，确信电机和所有被驱设备适合在传动单元提供的速度范围内运行。传动单元允许电动机、传动机械装置和被驱动设备在超出额定值的一定范围内运行。传动单元经过调整后可以使电机在高于和低于工频电网时的速度运行。

●在可能发生危险的情况下，不要激活标准应用程序的自动故障复位功能。如果激活，这些功能在故障发生后会复位传动单元并使传动单元继续运行。

●不要使用主电源断路器来控制电机，应使用控制盘键团和，或通过传动单元1/0板来实现。ACS 800直流电容器组的最大允许充电次数是10分钟内5次(例如直接电网充电)。

The transmission unit includes the following standard printed circuit boards:

● Main circuit interface board (AINT);

● Motor control and/O circuit board (RMIO-02) (connected to AINT via fiber optic):

● Input bridge control board (AINP);

● Input bridge protection board (AIBP) including varistors and buffers for thyristor rectifiers;

Power Supply Board (APOW):

● Gate control board [AGDR-61 or AGDR-62 (with du/dt limit option+E204)];

● Diagnostic and Control Panel Interface Board (ADPI):

● EMC filter board with option+E202 (NRFC and ARFC);

● Brake chopper control board (ABRC) with option+D150.

Before debugging the transmission unit and putting it into use, make sure that the motor and all driven equipment are suitable for operation within the speed range provided by the transmission unit. The transmission unit allows the motor, transmission machinery, and driven equipment to operate within a certain range beyond the rated value. The transmission unit can be adjusted to operate the motor at speeds higher and lower than the power frequency grid.

Do not activate the automatic fault reset function of standard applications in situations where danger may occur. If activated, these functions will reset the transmission unit and allow it to continue operating after a fault occurs.

Do not use the main power circuit breaker to control the motor. Instead, use the control panel key group or through the transmission unit 1/0 board. The maximum allowable charging frequency for ACS 800 DC capacitor banks is 5 times within 10 minutes (such as direct grid charging).
