GE IC758COWC15PCX512加固型6U VPX单板计算机

是一款加固型6U VPX单板计算机，专门为各种恶劣环境下的军事应用而设计，使先进的嵌入式计算解决方案的开发和部署更加经济高效。

主要特点在于配置了Intel? 1.86GHz Core?2 Duo (Penryn)处理器，具备6Mbyte的L2缓存和4Gbytes的DDR2 SDRAM。这些先进的特性可使客户开发高效耐用的解决方案，满足苛刻的I/O密集型应用的需求，例如图像处理、数字信号处理及无人机控制。

自2006年起，GE Fanuc智能平台一直在基于VPX架构的产品上保持领先地位。VPX以先进交换结构为中心，可以使我们的客户部署前所未有的高性能应用，从而平衡在VMEbus系统上的投资。SBC620进一步扩大了向客户提供的高性价比选项。图像及数字信号处理等嵌入式应用需要处理海量数据，而且在军事环境中需要尽可能的实时提供结果。SBC620等新产品为这些应用提供了极大的帮助，充分发挥了有效性并最终圆满完成任务。

特点是灵活性和I/O子系统的性能。板载Intel 5100芯片集（San Clemente）为VPX背板提供了四个x4 PCI Express? 通道，此外还有一个x8 PCI Express支持的XMC 插槽和一个x4 PCI Express支持的XMC 插槽。由于提供了六个USB 2.0端口、两个千兆以太网端口、两个SATA（每秒3 Gbit）端口以及两个RS232/422，使得I/O灵活性进一步增强。另外，SBC620还以XGI Volari? Z11图形处理器见长，从而支持双VGA或VGA/DVI输出。

I/O能力的提高还得益于PEX440子卡载卡，使SBC620能够使用最多三个子卡（两个PMC/XMC模块和一个AFIX附加弹性界面扩充模块）。PEX440为SBC610单板计算机和DSP230多处理器提供了相似的功能。

有五个加固等级，包括便于开发的对流冷却到便于部署的传导冷却宽温操作，并具有最佳每瓦性能，可以按照VITA-48 (REDI)标准选择性地配置外壳，实现两级维护。

GE Fanuc SBC620 Ruggedized 6U VPX Single Board Computer

SBC620 is a rugged 6U VPX single board computer designed specifically for military applications in various harsh environments, making the development and deployment of advanced embedded computing solutions more cost-effective.

The main feature is the configuration of Intel? 1.86GHz Core? 2 Duo (Penryn) processors with 6Mbytes of L2 cache and 4GBytes of DDR2 SDRAM. These advanced features enable customers to develop efficient and durable solutions to meet the demands of demanding I/O intensive applications, such as image processing, digital signal processing, and drone control.

Since 2006, the GE Fanuc intelligent platform has maintained a leading position in products based on VPX architecture. VPX is centered around advanced switching structures, allowing our customers to deploy unprecedented high-performance applications, thereby balancing investment in VMEbus systems. SBC620 further expands the cost-effective options available to customers. Embedded applications such as image and digital signal processing need to process massive amounts of data, and in military environments, real-time results need to be provided as much as possible. New products such as SBC620 have provided great assistance for these applications, fully leveraging their effectiveness and ultimately successfully completing the task.

The characteristics are flexibility and the performance of the I/O subsystem. The onboard Intel 5100 chipset (San Clemente) provides four x4 PCI Express for the VPX backplane? In addition, there is an XMC slot supported by x8 PCI Express and an XMC slot supported by x4 PCI Express. By providing six USB 2.0 ports, two Gigabit Ethernet ports, two SATA (3 Gbit per second) ports, and two RS232/422 ports, I/O flexibility is further enhanced. In addition, SBC620 also uses XGI Volari? The Z11 graphics processor is renowned for supporting dual VGA or VGA/DVI outputs.

The improvement in I/O capability also benefits from the PEX440 subcard, allowing SBC620 to use up to three subcards (two PMC/XMC modules and one AFIX additional elastic interface expansion module). The PEX440 provides similar functionality for SBC610 single board computers and DSP230 multiprocessors.

There are five reinforcement levels, including convection cooling for easy development to conduction cooling for wide temperature operation for easy deployment, and with optimal per watt performance, the shell can be selectively configured according to VITA-48 (REDI) standards to achieve two-stage maintenance.
